方軌和圓軌的不同之處

The difference between square and circular rails

　　主要體現在以下幾個方面：

Mainly reflected in the following aspects:

　　摩擦和負載能力：方軌是面接觸式摩擦，摩擦力較大，但負載均勻，需要經常上油潤滑。圓軌則是圓柱形的線型導軌，摩擦小，由于是一系列滾珠的點接觸，需要支撐的地方有限，剛性差，負載性能有限，僅載徑向有較好承載力，軸向承載比較小。

Friction and load capacity: Square rails are surface contact friction with high friction, but the load is uniform and requires frequent oil lubrication. Circular rails are cylindrical linear guides with low friction. Due to the point contact of a series of balls, the areas that need to be supported are limited, resulting in poor rigidity and limited load performance. They only have good radial bearing capacity and relatively small axial bearing capacity.

　　精度和重現性：方軌的定位精度高，重現性好，即使在微量進給時也不會有空轉打滑的現象，可以實現μm級的定位精度。圓軌的精度稍差，但如果制作得好，可以達到10根左右的精度。

Accuracy and reproducibility: The positioning accuracy of the square rail is high, with good reproducibility. Even during micro feed, there will be no slipping phenomenon, which can be achieved μ M-level positioning accuracy. The accuracy of circular rails is slightly poor, but if made well, it can reach an accuracy of about 10 pieces.

　　耐磨損和高速性能：方軌耐磨損，高速，阻力小，對設備的驅動馬力需求低，節省能源效果大，尤其運動磨耗小，溫升效應低。

Wear resistance and high-speed performance: Square rail wear resistance, high speed, low resistance, low demand for driving horsepower of equipment, great energy saving effect, especially low sports wear and low temperature rise effect.

　　應用環境：方軌在家具工業中可能不太適用，因為在家具廠中塵土飛揚的環境中很難保持清潔，容易造成機器堵塞。而圓軌則簡單，適用于多塵環境，易于維護。

Application environment: Square rails may not be suitable in the furniture industry because it is difficult to maintain cleanliness in dusty environments in furniture factories, which can easily cause machine blockage. The circular track is simple, suitable for dusty environments, and easy to maintain.

　　剛度和載荷能力：方形導軌產品能很好地滿足高剛度、高載荷應用的要求，通過精密磨削滾珠軌道，使導軌與滾珠準確匹配。圓形導軌產品的剛度和承載能力則相對較弱。

Stiffness and Load Capacity: Square guide rail products can meet the requirements of high stiffness and high load applications well. By precision grinding the ball track, the guide rail and ball are accurately matched. The stiffness and load-bearing capacity of circular guide rail products are relatively weak.

　　成本和安裝：圓導軌造價相對低廉、生產周期短、易于安裝等特性，在很多場合成為方型直線導軌的替代品。

Cost and installation: Circular guides have the characteristics of relatively low cost, short production cycle, and easy installation, making them a substitute for square linear guides in many situations.

　　綜上所述，方軌和圓軌的主要區別在于摩擦、負載能力、精度、耐磨損性、應用環境、剛度和載荷能力以及成本和安裝方面。方軌適用于高精度、高負載的應用場景，而圓軌則更適合于成本較低、多塵環境的應用場合。

In summary, the main differences between square and circular rails lie in friction, load capacity, accuracy, wear resistance, application environment, stiffness and load capacity, as well as cost and installation aspects. Square rails are suitable for high-precision and high load application scenarios, while circular rails are more suitable for low-cost and dusty environments.
